Longer, wider strap on toggle lighted switches provides 40% more contact area to wall board. Virtually eliminates floating installations. Industrial design cam action mechanism insures quiet switch action. Patented built-in wire stripper for #14 and #12 wire to speed installation. Unbreakable top and bottom housing eliminates call backs due to job site breakage. Patented built-in wire looper for pre-looping. Three-way switches feature additional push-in common termination for feed-through tapping. Push-in terminals accept #14 solid wire only. Side wire terminals accept up to #10 solid or stranded wire.

CONTROL FAN/LT ROTARY 4SPD WHT
Key Features Fully variable fan control allows for precise fan speed setting Replaces a standard switch and offers fan control capabilities Fan/light controls - rotary - white - single pole Adjust lights and fans together. For overhead light/fan combination fixtures. Rated for 1.5 amp fan and 300 watt light. Designed to operate ceiling fans using shaded pole or split capacitor motors only. 4 speed with wire leads. Ul listed. Eaton Cooper Wiring Combination Switch 300 W 1.5 A 1 Poles White For Rotary Fan Control/Dimmer Adjust lights and fans together. For overhead light/fan combination fixtures. Rated for 300 watt light. Designed to operate ceiling fans using shaded pole or split capacitor motors only. 4 speed with wire leads. UL Listed.

RECEPT DUPLEX RB 15A 125V 2P3Wt is virtually unbreakable. The 2008 National Electrical Code (NEC) states that "Effective January 1, 2008, all receptacles installed in new dwelling units must be tamper-resistant." Features a wire stripper for number 14 and number 12 wire, extra long and wide mounting straps and tri-combo screws that accept slotted, Phillips and Robertson-head tools. Terminal screws are backed out and ready to wire. Side-wire terminals accept up to number 10 solid or stranded wire. Push interminals accept number 14 solid wire. Screw-catch feature speeds wall plate installation. 15 amp, 125 volt. NEMA 5-15R. UL, cULus Listed.

Occupancy/vacancy sensor switches use advanced Passive Infrared (PIR) technology to sense the movement of heat-emitting bodies. Occupancy sensors provide auto-On/Off or manual-On/auto-Off operation while vacancy sensors provide manual-On/auto-Off operation only (CA Title 24 Compliant). The sensors automatically turn lights off after a space becomes vacant and a preset time delay elapses. Both versions provide 1-pole (single-location) and 3-way (multi-location) wiring and work with all lighting load types (INC, MLV, ELV, FLR, CFL, LED). A selectable and dimmable LED nightlight is provided. All sensors are compatible with any decorator-style or decorator screwless wallplate.

Eaton Wiring Devices' stylish passive infrared wallbox sensor provides a convenient energy saving lighting control alternative for 120 V applications. The sensor includes light level sensing capability to further enhance the energy savings by preventing automatic control of the lights when the ambient light level is sufficient. This sensor is easily installed in any standard wallbox to control most lighting loads and is available in six colors.

Eaton Wiring Devices' stylish passive infrared wallbox sensor provides a convenient energy saving lighting control alternative for 120 V applications. The sensor includes light level sensing capability to further enhance the energy savings by preventing automatic control of the lights when the ambient light level is sufficient. This sensor is easily installed in any standard wallbox to control most lighting loads and is available in six colors.

ADAPTER PWR W-CRD 20A TWST/LCK

Side wire terminals accept up to number 10 solid or stranded wire. Rated for fluorescent lighting fixtures typical in commercial applications. 0.050 in thick steel mounting strap zinc-plated for corrosion resistance. Ground screw terminal standard. 20 A, 120/277 V. Meets all UL 20 requirements, Federal Specifications WS 896.

RECEPTACLE TMPRPRF USBCHRG WHT
EATON USB Combination Receptacle, 125 VAC, 5 VDC, 15 A at 125 VAC, 36 A at 5 VDC, 140 kHz Frequency, 2 Pole, 3 Wires, 2 USB Ports, Screw Terminals, Side and Back Wiring, 14 to 12 AWG Wire, NEMA 515R, 4 to 140 deg F Operating, Thermoplastic, White, Dimensions 419 in H x 13 in W x 14 in D 2 USB Port.

EATON Receptacle, Duplex, TamperResistant, 125 V, 15 A, 3 Wires, 2 USB Ports, Grounded Wiring, NEMA 515R, Thermoplastic, Ivory.

RECEPT DPLX USB 15A 125V SG

DUPLEX OUTLEX 2P 15A 125V ALMOND

Eaton LED nightlight with duplex receptacle, Tamper-resistant, 14 to 12 AWG, 15 A, flush mount, 120/277 V, back and side wiring, white, brass, 5-15R, two-pole, three-wire, grounding, thermoplastic

Longer, wider strap on toggle switches provides 40% more contact area to wallboard. Virtually eliminates floating installations. Industrial design cam-action mechanism insures quiet switch action. Patented built-in wire stripper for #14 and #12 wire to speed installation. Unbreakable top and bottom housing eliminates call-backs due to jobsite breakage. Patented built-in wire looper for pre-looping. Three-way switches feature additional push-in common termination for feed-through tapping. Push-in terminals accept #14 solid wire only. Side wire terminals accept up to #10 solid or stranded wire. Tri-combo screws accept slotted, Phillips and Robertson head tools for installations in both the US and Canada.

Receptacles provide compliance with 2011 NEC Article 406.12 that states that all receptacles installed in dwelling units must be tamper-resistant. Durable impact-resistant thermoplastic face and back body is virtually unbreakable. "TR" designation provides visual identification. Terminal screws are backed out and ready to wire. Extra-long and extra-wide mounting straps with patented built-in wire stripper for #14 and #12 wire to speed installation. Side-wire terminals accept up to #10 solid or stranded wire and push-in terminals accept #14 solid wire.
